RIDGID
Drain Inspection Camera
RIDGID SeeSnake nanoReel Inspection Camera with CA-350 Handheld Camera | 77583
RIDGID SeeSnake nanoReel Inspection Camera with CA-350 Handheld Camera is a portable visual-inspection camera for examining difficult-to-access areas and internal spaces.Key featuresThe RIDGID SeeSnake® NanoReel Inspection Camera opens new possibilities in professional drain and pipe inspection, featuring the...
£4,100.00
ex VAT
£4,920.00
inc VAT
VAT and delivery calculated where applicable.
Not sure this is the right product?
Ask the Rausch UK team before ordering. Contact us
Ask the Rausch UK team before ordering. Contact us
Rausch UK support
Technical support from our UK team
Professional equipment
Equipment for drainage, utilities and industry
Need help choosing?
Speak to our team before you order
Product information
At a glance
SKU
77583
Brand
RIDGID
Product type
Drain Inspection Camera
Product overview
About this product
Product information, features and application details.
RIDGID SeeSnake nanoReel Inspection Camera with CA-350 Handheld Camera is a portable visual-inspection camera for examining difficult-to-access areas and internal spaces.
Key features
The RIDGID SeeSnake® NanoReel Inspection Camera opens new possibilities in professional drain and pipe inspection, featuring the smallest-diameter camera and most flexible push cable in the SeeSnake® range.
- Maneuverability– Small 15mm camera head with ultra flexible push cable navigates tight spaces.
- Portability– Lightweight and compact carrying case design is easy to carry to jobsites and store in between.
- Stability– Built-in kickstand can be used upright for tight spaces, at an angle for added leverage or on four feet to accommodate the CSx Via.
- Durability– Hardened stainless steel camera head & spring assembly is durable and reliable for a long service life.
- Visibility– Camera heads feature long-lasting high-efficiency LEDs that provide greater views inside pipes.
- Traceability– Integrated 512 Hz sonde allows for easy line tracing and locating.
- Versatility– Use with any SeeSnake monitor or Wi-Fi Hub.
Standard Equipment
- 71498 – Spare, Slipring Connector
- 67307 – Assy, Interconnect Cable, Overmolded, 3m (10’)
- 69758 – Kickstand Accessory
- 42778 – Kit, Pipe Guide 30mm OD & Camera Head Guide 25mm OD, 15.5mm Camera Head
- 55903 – CA-350 Handheld Inspection Camera, includes 12V Battery and Charger
- 67808 – SeeSnake® CA-350 Adapter and Docking Handle
Specifications
| Camera Diameter | 15.5 mm |
| Camera Type | Fixed |
| Resolution | 656 x 492 pixels |
| Line Capacity | 1″ to 2″ (25 mm to 51 mm) |
| Push Cable Length | 82 ft (25 m) |
| Push Cable Diameter | 0.28 in (7.2 mm) |
| Cable Flexibility | Ultra Flex |
| Push Cable Minimum Bend Radius | 1 in (25 mm) |
| Sonde | 512 Hz, Integrated |
| Weight | 12.7 lbs (5.7 kg) |
| Length | 13.3 in (337 mm) |
| Width | 8.8 in (224 mm) |
| Height | 16.2 in (411 mm) |
| Drum Diameter | 12 in (305 mm) |
Product identification
- Brand: RIDGID
- Manufacturer part number / MPN: 77583
- UPC / GTIN: 095691775832
- Product type: Handheld Inspection Camera
UK supply and support
Rausch UK is a RIDGID Authorised Repair Centre and provides UK technical support, service and after-sales assistance for professional RIDGID equipment.
